Solar Air Pump AP002

Solar Air Pump

Product Instruction

___________________________________________________________________

This product is an oxygenator powered by a solar panel and also can be charged by a power adapter. It  does not require any wiring, ensuring a quick and easy installation. It helps to increase oxygen levels to fishes when finishing or in fish tanks, aquariums. The solar panel should be placed in a well lit area to ensure enough sunlight exposure, and connect to the main unit before the air stones are dropped into the pond.

Product Specifications:

___________________________________________________________________

1. Solar panel: 5V 290MA

2. Battery: 18650 lithium battery 3.7V 2200mAH replacable

3. Pump: DC micro air pump 1.8V 150MA

            Sound: 50dB

            Minimum air flow: 0.3L/min

           Air nozzle specification: φ4.4MM

(the external air stone size is φ5.1MM)

4. Product working power range: 3.2V－4.2V 90MA

  Low battery indicator voltage (flashing green): 3.3V

  Full power indication voltage (red light on): 4.0V

  Over charging protection voltage: 4.2V

5. Working time on fully charged battery: about 5 hours

6. Charging method: with solar panel or 5V 1A power adapter
